Size
|
20 mm to 90 mm S & L
|
|
Standard
|
EN 50262 : 1999
|
|
Application
|
For indoor or outdoor use with all types of SWA Cable
|
|
Function
|
Provide for Environmental Seal in the Cable Outer sheath.
Also, provide mechanical cable retention & electrical continuity
|
|
Material
|
Brass BS 2874 CZ121 Pb3
|
|
Optional Threads
|
METRIC, NPT, BSP, PG or as specified
|
|
Finish
|
Brass Finish, Nickel Finish, Chrome Finish or as
specified
|
|
Operating Temp.
|
Standard seals -200 C to +800 C
|
|
Accessories
|
Matching Accessories available like PVC Shrouds, Lock
Nuts, Earth Tag, Reducers, Adaptors, etc. as per the requirement
|
|
Size
|
Thread
|
Length
|
A
|
B
|
A/F
|
A/C
|
|
20S
|
M20
|
15.00
|
12.00
|
16.00
|
22.20
|
24.20
|
|
20L
|
M20
|
15.00
|
14.00
|
20.50
|
27.00
|
29.50
|
|
20/16
|
M20
|
15.00
|
9.00
|
14.00
|
22.20
|
24.20
|
|
25S
|
M25
|
15.00
|
18.50
|
24.50
|
33.50
|
37.50
|
|
25L
|
M25
|
15.00
|
20.50
|
27.50
|
36.00
|
40.00
|
|
32S
|
M32
|
10.40
|
24.30
|
34.00
|
43.00
|
48.50
|
|
32L
|
M32
|
15.00
|
26.27
|
34.20
|
43.50
|
48.50
|
|
40S
|
M40
|
15.00
|
29.50
|
41.50
|
52.00
|
58.00
|
|
40L
|
M40
|
15.00
|
33.00
|
41.50
|
52.00
|
58.00
|
|
50S
|
M50
|
15.00
|
38.50
|
47.00
|
59.00
|
65.50
|
|
50L
|
M50
|
15.00
|
44.30
|
53.20
|
64.20
|
71.50
|
|
63S
|
M63
|
20.00
|
50.20
|
62.50
|
73.50
|
81.50
|
|
63L
|
M63
|
20.00
|
56.20
|
65.50
|
79.50
|
89.00
|
|
75S
|
M75
|
20.00
|
62.00
|
74.00
|
87.00
|
97.00
|
|
75L
|
M75
|
20.00
|
68.00
|
78.20
|
97.00
|
108.00
|
|
90L
|
M90
|
18.50
|
80.00
|
91.00
|
103.50
|
114.50
|
Also available in Kit Packaging and also as per the specification.
|
|
