Size |
20 mm to 90 mm S & L |
|
Standard |
BS 6121 |
|
Application |
Dry Indoor, for use with all types of SWA Cable |
|
Function |
Provide mechanical Cable Retention & Electrical Wire
continuity via Armoured Wire. |
|
Material |
Brass BS 2874 CZ121 Pb3 |
|
Optional Threads |
METRIC, NPT, BSP, PG or as specified |
|
Finish |
Brass Finish, Nickel Finish, Chrome Finish or as
specified |
|
Operating Temp. |
-800 C to +3000 C |
|
Accessories |
Matching Accessories available like PVC Shrouds, Lock
Nuts, Earth Tag, Reducers, Adaptors, etc. as per the requirement |
Technical Data:
|
Size |
Thread |
Length |
A |
B |
A/F |
A/C |
|
20S |
M20 |
10.00 |
13.00 |
18.00 |
23.50 |
26.00 |
|
20L |
M20 |
10.00 |
14.00 |
21.00 |
25.00 |
28.00 |
|
25S |
M25 |
10.00 |
18.00 |
24.00 |
31.00 |
35.50 |
|
25L |
M25 |
10.00 |
20.50 |
27.00 |
33.00 |
37.00 |
|
32S |
M32 |
10.00 |
27.00 |
33.50 |
40.50 |
45.50 |
|
32L |
M32 |
10.00 |
27.00 |
33.50 |
40.50 |
45.50 |
|
40S |
M40 |
13.00 |
31.50 |
39.50 |
45.50 |
50.50 |
|
40L |
M40 |
13.00 |
33.00 |
41.50 |
49.00 |
55.00 |
|
50S |
M50 |
13.00 |
39.50 |
48.50 |
56.50 |
63.50 |
|
50L |
M50 |
13.00 |
44.50 |
54.50 |
62.50 |
70.50 |
|
63S |
M63 |
14.00 |
50.20 |
59.20 |
68.80 |
77.00 |
|
63L |
M63 |
13.50 |
56.50 |
65.50 |
76.00 |
86.00 |
|
75S |
M75 |
15.00 |
63.50 |
72.00 |
84.00 |
94.50 |
|
75L |
M75 |
15.00 |
69.50 |
78.50 |
90.00 |
101.00 |
|
90S |
M90 |
20.00 |
76.00 |
85.00 |
100.00 |
111.20 |
|
90L |
M90 |
18.00 |
78.40 |
90.50 |
103.00 |
115.00 |
Also available in Kit Packaging and also as per the specification.
|
|
